Features

In our new "CSD series" Harmonic Drive®, which inherit the excellent performance characteristics of the "CSF series", weight and configuration compactness have been taken to new extremes.
"CSD series" Harmonic Drive® are offered in a series of 7 different component types, opening up new possibilities for motion control speed reducers.

• Thickness has been reduced to 1/2 that of the conventional CSF series
• Torque capacity is 70% of the CSF series
• Torsional rigidity is 80 to 90% of the CSF series
• The series is compatible with a hollow-shaft construction



Models & Symbols
1. Type: CSD series
2. Size: 14, 17, 20, 25, 32, 40, 50
3. Reduction ratio: 50, 100, 160
4. Models and symbols:
    - 2A-GR = Component type ("2A-R" for sizes 14 and 17)
       (Only component type is available for CSD Series.)
5. Specification:
    - None = Standard
    - SP = Special specification

  Specification
Size
Reduction ratio
Rated torque at 2000r/min
Allowable peak torque at start and stop
Allowable average torque
Allowable maximum momentary torque
Maximum input speed (Grease lubrication)
N·m
N·m
N·m
N·m
r/min

14
50
3.7
12
4.8
24
14000
100
5.4
19
7.7
31
17
50
11
23
18
48
10000
100
16
37
27
55
20
50
17
39
24
69
10000
100
28
57
34
76*
(65)
160
28
64
34
76*
(65)
25
50
27
69
38
127
7500
100
47
110
75
152*
(135)
160
47
123
75
152*
(135)
32
50
53
151
75
268
7000
100
96
233
151
359*
(331)
160
96
261
151
359*
(331)
40
50
96
281
137
480
5600
100
185
398
260
694*
(580)
160
206
453
316
694*
(580)
50
50
172
500
247
1000
4500
100
329
686
466
1440
160
370
823
590
1577*
(1315)

   Allowable momentaly peak torque (*) is limited by the clamping torque of the flexspline.

Product Drawing
(Unit:mm)
Symbol /Size
14
17
20
25
32
40
50
øA h7
50
60
70
85
110
135
170
B
11
12.5
14
17
22
27
33
øC H7
11
15
20
24
32
40
50
D
11
11
16
20
30
32
44
Mass(kg)
0.06
0.10
0.13
0.24
0.51
0.92
1.9

   Please confirm dimensions and specification with the drawing issued by Harmonic Drive Systems.
